Redis学习 –
二、链表
链表的声明与实现在/src/adlist.h
、/src/adlist.c
中
//双向链表
typedef struct listNode {
struct listNode *prev;
struct listNode *next;
void *value;
} listNode;
typedef struct listIter {
listNode *next;
int direction;
} listIter;
//每个链表使用一个list结构来表示,这个结构带有表头节点指针、表尾节点指针,以及链表长度等信息
typedef struct list {
listNode *head;
listNode *tail;
void *(*dup)(void *ptr);
void (*free)(void *ptr);
int (*match)(void *ptr, void *key);
unsigned long len;
} list;
通过为链表设置不同的类型特定函数,Redis的链表可以用来保存各种不同类型的值
三、字典
字典的声明与实现在src/dict.h
、src/dict.c
。字典是redis的底层基础,对数据库的增删改查也是构建在对字典的操作之上的
在源码注释中,字典叫哈希表(hash table),实现了insert/del/replace/find/get-random-element 这些操作,使用链式法处理哈希冲突
重要结构体定义:
- 哈希表节点实体
typedef struct dictEntry {
void *key;
union {
void *val;
uint64_t u64;
int64_t s64;
double d;
} v;
struct dictEntry *next; /* t */
void *metadata[]; /* An arbitrary number of bytes (starting at a
* pointer-aligned address) of size as returned
* by dictType"s dictEntryMetadataBytes(). */
} dictEntry;
- 类型方法接口
typedef struct dictType {
uint64_t (*hashFunction)(const void *key);
void *(*keyDup)(dict *d, const void *key);
void *(*valDup)(dict *d, const void *obj);
int (*keyCompare)(dict *d, const void *key1, const void *key2);
void (*keyDestructor)(dict *d, void *key);
void (*valDestructor)(dict *d, void *obj);
int (*expandAllowed)(size_t moreMem, double usedRatio);
/* Allow a dictEntry to carry extra caller-defined metadata. The
* extra memory is initialized to 0 when a dictEntry is allocated. */
size_t (*dictEntryMetadataBytes)(dict *d);
} dictType;
- 哈希表结构实现
struct dict {
//dictType 包含了一系列的方法
dictType *type;
//dictEntry结构保存着一个键值对
dictEntry **ht_table[2];
unsigned long ht_used[2];
long rehashidx; /* rehashing not in progress if rehashidx == -1 */
/* Keep small vars at end for optimal (minimal) struct padding */
int16_t pauserehash; /* If >0 rehashing is paused (<0 indicates coding error) */
signed char ht_size_exp[2]; /* exponent of size. (size = 1<<exp) */
};
