java WebSocket 即时通讯配置使用说明

java WebSocket 即时通讯配置使用说明

1. 后台 启动类,执行main方法启动

package com.fh;
import java.io.IOException;
import java.net.InetSocketAddress;
import java.net.UnknownHostException;
import java.util.Date;

import net.sf.json.JSONObject;

import org.java_websocket.WebSocket;
import org.java_websocket.WebSocketImpl;
import org.java_websocket.framing.Framedata;
import org.java_websocket.handshake.ClientHandshake;
import org.java_websocket.server.WebSocketServer;


/**
 * @author FH
 * from fhadmin.cn
 * 2021-5-16
 */
public class ChatServer extends WebSocketServer{

	public ChatServer(int port) throws UnknownHostException {
		super(new InetSocketAddress(port));
	}

	public ChatServer(InetSocketAddress address) {
		super(address);
	}

	/**
	 * 触发连接事件
	 */
	@Override
	public void onOpen( WebSocket conn, ClientHandshake handshake ) {
		//this.sendToAll( "new connection: " + handshake.getResourceDescriptor() );
		//System.out.println( conn.getRemoteSocketAddress().getAddress().getHostAddress());
	}

	/**
	 * 触发关闭事件
	 */
	@Override
	public void onClose( WebSocket conn, int code, String reason, boolean remote ) {
		userLeave(conn);
	}

	/**
	 * 客户端发送消息到服务器时触发事件
	 */
	@Override
	public void onMessage(WebSocket conn, String message){
		message = message.toString();
		if(null != message && message.startsWith("FHadmin313596790")){
			this.userjoin(message.replaceFirst("FHadmin313596790", ""),conn);
		}if(null != message && message.startsWith("LeaveFHadmin313596790")){
			this.userLeave(conn);
		}if(null != message && message.contains("fhadmin886")){
			String toUser = message.substring(message.indexOf("fhadmin886")+10, message.indexOf("fhfhadmin888"));
			message = message.substring(0, message.indexOf("fhadmin886")) +"[私信]  "+ message.substring(message.indexOf("fhfhadmin888")+12, message.length());
			ChatServerPool.sendMessageToUser(ChatServerPool.getWebSocketByUser(toUser),message);//向所某用户发送消息
			ChatServerPool.sendMessageToUser(conn, message);//同时向本人发送消息
		}else{
			ChatServerPool.sendMessage(message.toString());//向所有在线用户发送消息
		}
	}

	public void onFragment( WebSocket conn, Framedata fragment ) {
	}

	/**
	 * 触发异常事件
	 */
	@Override
	public void onError( WebSocket conn, Exception ex ) {
		ex.printStackTrace();
		if( conn != null ) {
			//some errors like port binding failed may not be assignable to a specific websocket
		}
	}


	/**
	 * 用户加入处理
	 * @param user
	 */
	public void userjoin(String user, WebSocket conn){
		JSONObject result = new JSONObject();
		result.element("type", "user_join");
		result.element("user", "<a onclick="toUserMsg(""+user+"");">"+user+"</a>");
		ChatServerPool.sendMessage(result.toString());				//把当前用户加入到所有在线用户列表中
		String joinMsg = "{"from":"[系统]","content":""+user+"上线了","timestamp":"+new Date().getTime()+","type":"message"}";
		ChatServerPool.sendMessage(joinMsg);						//向所有在线用户推送当前用户上线的消息
		result = new JSONObject();
		result.element("type", "get_online_user");
		ChatServerPool.addUser(user,conn);							//向连接池添加当前的连接对象
		result.element("list", ChatServerPool.getOnlineUser());
		ChatServerPool.sendMessageToUser(conn, result.toString());	//向当前连接发送当前在线用户的列表
	}

	/**
	 * 用户下线处理
	 * @param user
	 */
	public void userLeave(WebSocket conn){
		String user = ChatServerPool.getUserByKey(conn);
		boolean b = ChatServerPool.removeUser(conn);				//在连接池中移除连接
		if(b){
			JSONObject result = new JSONObject();
			result.element("type", "user_leave");
			result.element("user", "<a onclick="toUserMsg(""+user+"");">"+user+"</a>");
			ChatServerPool.sendMessage(result.toString());			//把当前用户从所有在线用户列表中删除
			String joinMsg = "{"from":"[系统]","content":""+user+"下线了","timestamp":"+new Date().getTime()+","type":"message"}";
			ChatServerPool.sendMessage(joinMsg);					//向在线用户发送当前用户退出的消息
		}
	}
	public static void main( String[] args ) throws InterruptedException , IOException {
		WebSocketImpl.DEBUG = false;
		int port = 8887; //端口
		ChatServer s = new ChatServer(port);
		s.start();
		//System.out.println( "服务器的端口" + s.getPort() );
	}

}

2.ChatServerPool.java

package com.fh;

import java.util.ArrayList;
import java.util.Collection;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
import java.util.Set;

import org.java_websocket.WebSocket;

/**
 * @author FH
 * from fhadmin.cn
 * 2021-5-16
 */
public class ChatServerPool {

	/*保存连接的MAP容器*/
	private static final Map<WebSocket,String> userconnections = new HashMap<WebSocket,String>();

	/**
	 * 获取用户名
	 * @param session
	 */
	public static String getUserByKey(WebSocket conn){
		return userconnections.get(conn);
	}

	/**
	 * 获取WebSocket
	 * @param user
	 */
	public static WebSocket getWebSocketByUser(String user){
		Set<WebSocket> keySet = userconnections.keySet();
		synchronized (keySet) {
			for (WebSocket conn : keySet) {
				String cuser = userconnections.get(conn);
				if(cuser.equals(user)){
					return conn;
				}
			}
		}
		return null;
	}

	/**
	 * 向连接池中添加连接
	 * @param inbound
	 */
	public static void addUser(String user, WebSocket conn){
		userconnections.put(conn,user);	//添加连接
	}

	/**
	 * 获取所有的在线用户
	 * @return
	 */
	public static Collection<String> getOnlineUser(){
		List<String> setUsers = new ArrayList<String>();
		Collection<String> setUser = userconnections.values();
		for(String u:setUser){
			setUsers.add("<a onclick="toUserMsg(""+u+"");">"+u+"</a>");
		}
		return setUsers;
	}

	/**
	 * 移除连接池中的连接
	 * @param inbound
	 */
	public static boolean removeUser(WebSocket conn){
		if(userconnections.containsKey(conn)){
			userconnections.remove(conn);	//移除连接
			return true;
		}else{
			return false;
		}
	}

	/**
	 * 向特定的用户发送数据
	 * @param user
	 * @param message
	 */
	public static void sendMessageToUser(WebSocket conn,String message){
		if(null != conn && null != userconnections.get(conn)){
			conn.send(message);
		}
	}

	/**
	 * 向所有的用户发送消息
	 * @param message
	 */
	public static void sendMessage(String message){
		Set<WebSocket> keySet = userconnections.keySet();
		synchronized (keySet) {
			for (WebSocket conn : keySet) {
				String user = userconnections.get(conn);
				if(user != null){
					conn.send(message);
				}
			}
		}
	}
}

3.前端


var websocket;
var isCreatw = false;
var title="";
var win;
var input;
var isQj = true;
var toUser="";
function toUserMsg(toU){
	if((!isQj && toUser == toU) || toU == user){
		win.setTitle(title + "&nbsp;&nbsp;(已连接)   【现在全局对话】");
		isQj = true;
		toUser = "";
	}else{
		win.setTitle(title + "&nbsp;&nbsp;(已连接)   【现在单独与"+toU+"对话】");
		isQj = false;
		toUser = toU;
	}
}
 function creatw() {
	 		if(isCreatw){
	 			alert("已经启动");
	 			return;
	 		}else{
	 			isCreatw = true;
	 		}
			//创建用户输入框
			input = Ext.create("Ext.form.field.HtmlEditor", {
						region : "south",
						height : 120,
						enableFont : false,
						enableSourceEdit : false,
						enableAlignments : false,
						listeners : {
							initialize : function() {
								Ext.EventManager.on(me.input.getDoc(), {
											keyup : function(e) {
												if (e.ctrlKey === true
														&& e.keyCode == 13) {
													e.preventDefault();
													e.stopPropagation();
													send();
												}
											}
										});
							}
						}
					});

			//创建消息展示容器
			var output = Ext.create("MessageContainer", {
						region : "center"
					});

			var dialog = Ext.create("Ext.panel.Panel", {
						region : "center",
						layout : "border",
						items : [input, output],
						buttons : [{
									text : "发送",
									handler : send
								}]
					});

			//初始话WebSocket
			function initWebSocket() {
				if (window.WebSocket) {
					websocket = new WebSocket(encodeURI("ws://127.0.0.1:8887"));

					websocket.onopen = function() {
						//连接成功
						win.setTitle(title + "&nbsp;&nbsp;(已连接)   【现在全局对话】");
						websocket.send("FHadmin313596790"+user);
					}
					websocket.onerror = function() {
						//连接失败
						win.setTitle(title + "&nbsp;&nbsp;(连接发生错误)");
					}
					websocket.onclose = function() {
						//连接断开
						win.setTitle(title + "&nbsp;&nbsp;(已经断开连接)");
					}
					//消息接收
					websocket.onmessage = function(message) {
						var message = JSON.parse(message.data);
						//接收用户发送的消息
						if (message.type == "message") {
							output.receive(message);
						} else if (message.type == "get_online_user") {
							//获取在线用户列表
							var root = onlineUser.getRootNode();
							Ext.each(message.list,function(user){
								var node = root.createNode({
									id : user,
									text : user,
									iconCls : "user",
									leaf : true
								});
								root.appendChild(node);
							});
						} else if (message.type == "user_join") {
							//用户上线
								var root = onlineUser.getRootNode();
								var user = message.user;
								var node = root.createNode({
									id : user,
									text : user,
									iconCls : "user",
									leaf : true
								});
								root.appendChild(node);
						} else if (message.type == "user_leave") {
								//用户下线
								var root = onlineUser.getRootNode();
								var user = message.user;
								var node = root.findChild("id",user);
								root.removeChild(node);
						}
					}
				}
			};

			//在线用户树
			var onlineUser = Ext.create("Ext.tree.Panel", {
						title : "在线用户",
						rootVisible : false,
						region : "east",
						width : 150,
						lines : false,
						useArrows : true,
						autoScroll : true,
						split : true,
						iconCls : "user-online",
						store : Ext.create("Ext.data.TreeStore", {
									root : {
										text : "在线用户",
										expanded : true,
										children : []
									}
								})
					});

			title = "欢迎您:" + user;
			//展示窗口
			win = Ext.create("Ext.window.Window", {
						title : title + "&nbsp;&nbsp;(未连接)",
						layout : "border",
						iconCls : "user-win",
						minWidth : 650,
						minHeight : 460,
						width : 650,
						animateTarget : "websocket_button",
						height : 460,
						items : [dialog,onlineUser],
						border : false,
						listeners : {
							render : function() {
								initWebSocket();
							}
						}
					});

			win.show();

			win.on("close",function(){
				websocket.send("LeaveFHadmin313596790");
				isCreatw = false;
			 });

			//发送消息
			function send() {
				var content = input.getValue();
				if(toUser != ""){content = "fhadmin886"+toUser+"fhfhadmin888" + content;}
				var message = {};
				if (websocket != null) {
					if (input.getValue()) {
						Ext.apply(message, {
									from : user,
									content : content,
									timestamp : new Date().getTime(),
									type : "message"
								});
						websocket.send(JSON.stringify(message));
						//output.receive(message);
						input.setValue("");
					}
				} else {
					Ext.Msg.alert("提示", "您已经掉线,无法发送消息!");
				}
			}
};

//用于展示用户的聊天信息
Ext.define("MessageContainer", {

	extend : "Ext.view.View",

	trackOver : true,

	multiSelect : false,

	itemCls : "l-im-message",

	itemSelector : "div.l-im-message",

	overItemCls : "l-im-message-over",

	selectedItemCls : "l-im-message-selected",

	style : {
		overflow : "auto",
		backgroundColor : "#fff"
	},

	tpl : [
			"<div class="l-im-message-warn">​欢迎使用FH Admin 即时通讯系统。</div>",
			"<tpl for=".">",
			"<div class="l-im-message">",
			"<div class="l-im-message-header l-im-message-header-{source}">{from}  {timestamp}</div>",
			"<div class="l-im-message-body">{content}</div>", "</div>",
			"</tpl>"],

	messages : [],

	initComponent : function() {
		var me = this;
		me.messageModel = Ext.define("Leetop.im.MessageModel", {
					extend : "Ext.data.Model",
					fields : ["from", "timestamp", "content", "source"]
				});
		me.store = Ext.create("Ext.data.Store", {
					model : "Leetop.im.MessageModel",
					data : me.messages
				});
		me.callParent();
	},

	//将服务器推送的信息展示到页面中
	receive : function(message) {
		var me = this;
		message["timestamp"] = Ext.Date.format(new Date(message["timestamp"]),
				"H:i:s");
		if(message.from == user){
			message.source = "self";
		}else{
			message.source = "remote";
		}
		me.store.add(message);
		if (me.el.dom) {
			me.el.dom.scrollTop = me.el.dom.scrollHeight;
		}
	}
});
