wen 使用feilong发企业微信机器人
使用 #feilong# https://www.oschina.net/p/feilong 发企业微信机器人
企业微信机器人在日常的使用场景中越来越多, 比如服务器关键任务告警,定时发通知提醒等等, 和短信相比即免费又不像短信逐渐只有接收验证码的功能, 那么问题来了,如何使用feilong来发送企业微信机器人呢?
简单 3 步
第1步: jar 依赖
必要依赖
<dependency>
<groupId>com.github.ifeilong</groupId>
<artifactId>feilong</artifactId>
<version>3.0.9</version>
</dependency>
<dependency>
<groupId>org.apache.httpcomponents</groupId>
<artifactId>httpmime</artifactId>
<version>4.5.12</version>
<exclusions>
<exclusion>
<artifactId>httpclient</artifactId>
<groupId>org.apache.httpcomponents</groupId>
</exclusion>
</exclusions>
</dependency>
<dependency>
<groupId>org.apache.httpcomponents</groupId>
<artifactId>httpclient</artifactId>
<version>4.5.12</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-beans</artifactId>
<version>5.2.7.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-context</artifactId>
<version>5.2.7.RELEASE</version>
</dependency>
for test 和日志
<!--下面是for test 和日志-->
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-test</artifactId>
<version>5.2.7.RELEASE</version>
<scope>test</scope>
</dependency>
<dependency>
<groupId>org.slf4j</groupId>
<artifactId>slf4j-api</artifactId>
<version>1.7.30</version>
</dependency>
<dependency>
<groupId>org.slf4j</groupId>
<artifactId>slf4j-log4j12</artifactId>
<version>1.7.30</version>
</dependency>
<dependency>
<groupId>log4j</groupId>
<artifactId>log4j</artifactId>
<version>1.2.17</version>
</dependency>
<dependency>
<groupId>junit</groupId>
<artifactId>junit</artifactId>
<version>4.13</version>
<scope>test</scope>
</dependency>
<dependency>
<groupId>org.hamcrest</groupId>
<artifactId>hamcrest-library</artifactId>
<version>1.3</version>
<scope>test</scope>
</dependency>
第2步: 使用xml 配置机器人
wxbot.xml
注意xml中需要使用feilong 的customer xml tag
feilong:wxworkBot 只有一个核心自定义属性, key 是企业微信机器人对应的key , key 参考 <a href="https://work.weixin.qq.com/help?person_id=1&doc_id=13376">如何配置群机器人？</a>
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:feilong="http://www.feilong.com/schema/feilong"
xsi:schemaLocation="
http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
http://www.feilong.com/schema/feilong http://www.feilong.com/schema/feilong/feilong.xsd
">
<feilong:wxworkBot id="wxworkBot" key="80fa900e-c601-41a9-987c-ffa48f1d9e27" />
</beans>
第3步: 使用
简单小示例:
package com.feilong.namespace;
import static org.hamcrest.MatcherAssert.assertThat;
import static org.hamcrest.Matchers.allOf;
import static org.hamcrest.Matchers.hasProperty;
import static org.hamcrest.Matchers.is;
import org.junit.Test;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.test.context.ContextConfiguration;
import org.springframework.test.context.junit4.AbstractJUnit4SpringContextTests;
import com.feilong.net.wxwork.bot.WxworkBot;
import com.feilong.net.wxwork.bot.message.WxworkResponse;
@ContextConfiguration(locations = { "classpath*:wxbot.xml" })
public class WxworkBotTagTest extends AbstractJUnit4SpringContextTests{
@Autowired
@Qualifier("wxworkBot")
private WxworkBot wxworkBot;
//---------------------------------------------------------------
@Test
public void test(){
WxworkResponse wxworkResponse = wxworkBot.sendMessage("hello world");
assertThat(
wxworkResponse,
allOf(
hasProperty("isSuccess", is(true)), //
hasProperty("errcode", is("0"))));
}
}
执行这个单元测试, 你将会收到企业微信机器人发的消息
关于 WxworkBot
com.feilong.net.wxwork.bot.WxworkBot 提供了2个易用的方法
- sendMessage(String) 发送普通消息,以及Markdown格式的消息
- sendNewsMessage(Article…) 发送推送图文类型消息
sendMessage(String) 发送普通消息,以及Markdown格式的消息
在上述 hello world示例中, 你可以看到发送简单消息, 也支持markdown格式的消息, 比如
@Test
public void test(){
wxworkBot.sendMessage(
"实时新增用户反馈<font color="warning">132例</font>，请相关同事注意。
" + "> 类型:<font color="comment">用户反馈</font>
"
+ "> 普通用户反馈:<font color="comment">117例</font>
"
+ "> VIP用户反馈:<font color="comment">15例</font>");
}
效果:
sendNewsMessage(Article…) 发送推送图文类型消息
你还可以使用sendNewsMessage 来推送图文类型的消息,
package com.feilong.namespace;
import org.junit.Test;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.test.context.ContextConfiguration;
import org.springframework.test.context.junit4.AbstractJUnit4SpringContextTests;
import com.feilong.net.wxwork.bot.WxworkBot;
import com.feilong.net.wxwork.bot.message.news.Article;
@ContextConfiguration(locations = { "classpath*:wxbot.xml" })
public class WxworkBotTagNewsMessageTest extends AbstractJUnit4SpringContextTests{
@Autowired
@Qualifier("wxworkBot")
private WxworkBot wxworkBot;
@Test
public void test(){
//是 标题，不超过128个字节，超过会自动截断
String title = "提醒您,点击填Timesheet";
//描述，不超过512个字节，超过会自动截断
String description = "@all 点我直接填写Jira Timesheet" + "
" + "我爱工作,工作使我快乐";
//"点我直接填写Jira Timesheet",
String url = "http://jira.xxx.cn/plugins/servlet/aio-ts/bridge/pages/aiotimeentry";
String img = "https://timgsa.baidu.com/timg?image&quality=80&size=b9999_10000&sec=1585320605587&di=9424f8862476b2ce819ac9f5637567b1&imgtype=0&src=http%3A%2F%2Fimgsrc.baidu.com%2Fimgad%2Fpic%2Fitem%2F503d269759ee3d6d55e89bf048166d224f4adeda.jpg";
wxworkBot.sendNewsMessage(new Article(title, description, url, img));
}
}
效果:
–完
