Spring Bean 标签解析

Spring Bean 标签解析

上一篇文章讲到了标签在 parseDefaultElement 方法中进行解析,本篇文章将讲解这部分内容

bean 标签解析

查看 processBeanDefinition 方法,针对各个操作作具体分析:

protected void processBeanDefinition(Element ele, BeanDefinitionParserDelegate delegate) {
    // 1.解析 BeanDefinition
    BeanDefinitionHolder bdHolder = delegate.parseBeanDefinitionElement(ele);
    if (bdHolder != null) {
        bdHolder = delegate.decorateBeanDefinitionIfRequired(ele, bdHolder);
        try {
            BeanDefinitionReaderUtils.registerBeanDefinition(bdHolder, this.getReaderContext().getRegistry());
        } catch (BeanDefinitionStoreException var5) {
            this.getReaderContext().error("Failed to register bean definition with name "" + bdHolder.getBeanName() + """, ele, var5);
        }
        this.getReaderContext().fireComponentRegistered(new BeanComponentDefinition(bdHolder));
    }
}

1. 解析 BeanDefinition

首先从元素解析及信息提取开始,进入 parseBeanDefinitionElement 方法

public BeanDefinitionHolder parseBeanDefinitionElement(Element ele) {
    return this.parseBeanDefinitionElement(ele, (BeanDefinition)null);
}

public BeanDefinitionHolder parseBeanDefinitionElement(Element ele, @Nullable BeanDefinition containingBean) {
    // 1.1 解析id属性
    String id = ele.getAttribute("id");
    // 1.2 解析name属性
    String nameAttr = ele.getAttribute("name");
    List<String> aliases = new ArrayList();
    if (StringUtils.hasLength(nameAttr)) {
        String[] nameArr = StringUtils.tokenizeToStringArray(nameAttr, ",; ");
        aliases.addAll(Arrays.asList(nameArr));
    }

    String beanName = id;
    if (!StringUtils.hasText(id) && !aliases.isEmpty()) {
        beanName = (String)aliases.remove(0);
        if (this.logger.isTraceEnabled()) {
            this.logger.trace("No XML "id" specified - using "" + beanName + "" as bean name and " + aliases + " as aliases");
        }
    }

    if (containingBean == null) {
        this.checkNameUniqueness(beanName, aliases, ele);
    }
	// 2. 解析其他属性
    AbstractBeanDefinition beanDefinition = this.parseBeanDefinitionElement(ele, beanName, containingBean);
    if (beanDefinition != null) {
        if (!StringUtils.hasText(beanName)) {
            try {
                // 3. 如果不存在beanName就根据Spring提供的命名规则为当前bean生成对应的beanName
                if (containingBean != null) {
                    beanName = BeanDefinitionReaderUtils.generateBeanName(beanDefinition, this.readerContext.getRegistry(), true);
                } else {
                    beanName = this.readerContext.generateBeanName(beanDefinition);
                    String beanClassName = beanDefinition.getBeanClassName();
                    if (beanClassName != null && beanName.startsWith(beanClassName) && beanName.length() > beanClassName.length() && !this.readerContext.getRegistry().isBeanNameInUse(beanClassName)) {
                        aliases.add(beanClassName);
                    }
                }

                if (this.logger.isTraceEnabled()) {
                    this.logger.trace("Neither XML "id" nor "name" specified - using generated bean name [" + beanName + "]");
                }
            } catch (Exception var9) {
                this.error(var9.getMessage(), ele);
                return null;
            }
        }

        String[] aliasesArray = StringUtils.toStringArray(aliases);
        // 4. 封装到 BeanDefinitionHolder 的实例
        return new BeanDefinitionHolder(beanDefinition, beanName, aliasesArray);
    } else {
        return null;
    }
}

该方法完成的主要工作包括以下内容:

  1. 提取元素中的 id 以及 name 属性
  2. 进一步解析其他属性并统一封装至 GenericBeanDefinition 类型的实例中
  3. 如果检测到 bean 没有指定 beanName,那么使用默认规则为此 Bean 生成 beanName
  4. 将获取到的信息封装到 BeanDefinitionHolder 的实例中

进一步查看步骤二对标签的其他属性的解析过程:

public AbstractBeanDefinition parseBeanDefinitionElement(Element ele, String beanName, @Nullable BeanDefinition containingBean) {
    this.parseState.push(new BeanEntry(beanName));
    String className = null;
    // 解析class属性
    if (ele.hasAttribute("class")) {
        className = ele.getAttribute("class").trim();
    }
	// 解析parent属性
    String parent = null;
    if (ele.hasAttribute("parent")) {
        parent = ele.getAttribute("parent");
    }

    try {
        // 创建用于承载属性的AbstractBeanDefinition类型的GenericBeanDefinition实例
        AbstractBeanDefinition bd = this.createBeanDefinition(className, parent);
        // 硬编码解析默认bean的各种属性
        this.parseBeanDefinitionAttributes(ele, beanName, containingBean, bd);
        // 提取description
        bd.setDescription(DomUtils.getChildElementValueByTagName(ele, "description"));
        // 解析元数据
        this.parseMetaElements(ele, bd);
        // 解析lookup-method属性
        this.parseLookupOverrideSubElements(ele, bd.getMethodOverrides());
        // 解析replaced-method属性
        this.parseReplacedMethodSubElements(ele, bd.getMethodOverrides());
        // 解析构造函数参数
        this.parseConstructorArgElements(ele, bd);
        // 解析property子元素
        this.parsePropertyElements(ele, bd);
        // 解析qualifier子元素
        this.parseQualifierElements(ele, bd);
        bd.setResource(this.readerContext.getResource());
        bd.setSource(this.extractSource(ele));
        AbstractBeanDefinition var7 = bd;
        return var7;
    } catch (ClassNotFoundException var13) {
        this.error("Bean class [" + className + "] not found", ele, var13);
    } catch (NoClassDefFoundError var14) {
        this.error("Class that bean class [" + className + "] depends on not found", ele, var14);
    } catch (Throwable var15) {
        this.error("Unexpected failure during bean definition parsing", ele, var15);
    } finally {
        this.parseState.pop();
    }

    return null;
}

接下来,我们继续一些复杂标签属性的解析:

1.1 创建用于属性承载的 BeanDefinition

BeanDefinition 是一个接口,在 Spring 中存在三种实现:RootBeanDefinition、ChildBeanDefinition、GenericBeanDefinition,三种实现类均继承了 AbstractBeanDefinition

BeanDefinition 是配置文件 <bean> 元素标签在容器中的内部表示形式,<bean> 标签拥有 class、scope、lazy-init 等配置属性,BeanDefinition 就提供了对应的 beanClass、scope、lazyInit 属性

由此可见,要解析属性首先要创建用于承载属性的实例,也就是创建 GenericBeanDefinition 类型的实例,createBeanDefinition 方法的作用就是实现此功能

public static AbstractBeanDefinition createBeanDefinition(@Nullable String parentName, @Nullable String className, @Nullable ClassLoader classLoader) throws ClassNotFoundException {
    GenericBeanDefinition bd = new GenericBeanDefinition();
    bd.setParentName(parentName);
    if (className != null) {
        // 如果classLoader不为空,则使用传入的classLoader加载对象
        // 否则就只是记录className
        if (classLoader != null) {
            bd.setBeanClass(ClassUtils.forName(className, classLoader));
        } else {
            bd.setBeanClassName(className);
        }
    }

    return bd;
}
2. 解析各种属性

当我们创建了 bean 信息的承载实例后,便可以进行 bean 信息的各种属性解析了,parseBeanDefinitionAttributes 方法是对 element 所有元素属性进行解析:

public AbstractBeanDefinition parseBeanDefinitionAttributes(Element ele, String beanName, @Nullable BeanDefinition containingBean, AbstractBeanDefinition bd) {
    // 解析scope属性
    if (ele.hasAttribute("singleton")) {
        this.error("Old 1.x "singleton" attribute in use - upgrade to "scope" declaration", ele);
    } else if (ele.hasAttribute("scope")) {
        bd.setScope(ele.getAttribute("scope"));
    } else if (containingBean != null) {
        bd.setScope(containingBean.getScope());
    }
	// 解析singleton属性
    if (ele.hasAttribute("abstract")) {
        bd.setAbstract("true".equals(ele.getAttribute("abstract")));
    }
	// 解析lazy-init属性
    String lazyInit = ele.getAttribute("lazy-init");
    if (this.isDefaultValue(lazyInit)) {
        lazyInit = this.defaults.getLazyInit();
    }
	// 若没有设置或设置成其他字符都会被设置为false
    bd.setLazyInit("true".equals(lazyInit));
    String autowire = ele.getAttribute("autowire");
    bd.setAutowireMode(this.getAutowireMode(autowire));
    String autowireCandidate;
    if (ele.hasAttribute("depends-on")) {
        autowireCandidate = ele.getAttribute("depends-on");
        bd.setDependsOn(StringUtils.tokenizeToStringArray(autowireCandidate, ",; "));
    }
	// 解析autowire属性
    autowireCandidate = ele.getAttribute("autowire-candidate");
    String destroyMethodName;
    if (this.isDefaultValue(autowireCandidate)) {
        destroyMethodName = this.defaults.getAutowireCandidates();
        if (destroyMethodName != null) {
            String[] patterns = StringUtils.commaDelimitedListToStringArray(destroyMethodName);
            bd.setAutowireCandidate(PatternMatchUtils.simpleMatch(patterns, beanName));
        }
    } else {
        bd.setAutowireCandidate("true".equals(autowireCandidate));
    }
	// 解析primary属性
    if (ele.hasAttribute("primary")) {
        bd.setPrimary("true".equals(ele.getAttribute("primary")));
    }
	// 解析init-method属性
    if (ele.hasAttribute("init-method")) {
        destroyMethodName = ele.getAttribute("init-method");
        bd.setInitMethodName(destroyMethodName);
    } else if (this.defaults.getInitMethod() != null) {
        bd.setInitMethodName(this.defaults.getInitMethod());
        bd.setEnforceInitMethod(false);
    }
	// 解析destroy-method属性
    if (ele.hasAttribute("destroy-method")) {
        destroyMethodName = ele.getAttribute("destroy-method");
        bd.setDestroyMethodName(destroyMethodName);
    } else if (this.defaults.getDestroyMethod() != null) {
        bd.setDestroyMethodName(this.defaults.getDestroyMethod());
        bd.setEnforceDestroyMethod(false);
    }
	// 解析factory-method属性
    if (ele.hasAttribute("factory-method")) {
        bd.setFactoryMethodName(ele.getAttribute("factory-method"));
    }
	// 解析factory-bean属性
    if (ele.hasAttribute("factory-bean")) {
        bd.setFactoryBeanName(ele.getAttribute("factory-bean"));
    }
    return bd;
}

注册解析的 BeanDefinition

得到 BeanDefinition 后,剩下的工作就是注册了,也就是 processBeanDefinition 方法中的

registerBeanDefinition 方法

protected void processBeanDefinition(Element ele, BeanDefinitionParserDelegate delegate) {
    BeanDefinitionHolder bdHolder = delegate.parseBeanDefinitionElement(ele);
    if (bdHolder != null) {
        bdHolder = delegate.decorateBeanDefinitionIfRequired(ele, bdHolder);

        try {
            // 注册解析的 BeanDefinition
            BeanDefinitionReaderUtils.registerBeanDefinition(bdHolder, this.getReaderContext().getRegistry());
        } catch (BeanDefinitionStoreException var5) {
            this.getReaderContext().error("Failed to register bean definition with name "" + bdHolder.getBeanName() + """, ele, var5);
        }
        this.getReaderContext().fireComponentRegistered(new BeanComponentDefinition(bdHolder));
    }
}

public static void registerBeanDefinition(BeanDefinitionHolder definitionHolder, BeanDefinitionRegistry registry) throws BeanDefinitionStoreException {
    // 使用beanName做唯一标识注册
    String beanName = definitionHolder.getBeanName();
    registry.registerBeanDefinition(beanName, definitionHolder.getBeanDefinition());
    // 注册所有的别名
    String[] aliases = definitionHolder.getAliases();
    if (aliases != null) {
        String[] var4 = aliases;
        int var5 = aliases.length;
        for(int var6 = 0; var6 < var5; ++var6) {
            String alias = var4[var6];
            registry.registerAlias(beanName, alias);
        }
    }
}

解析的 beanDefinition 都会被注册到 BeanDefinitionRegistry 类型的实例 registry 中,而对于 beanDefinition 的注册分成两个部分:通过 beanName 注册以及通过别名注册

1. 通过 beanName 注册

public void registerBeanDefinition(String beanName, BeanDefinition beanDefinition) throws BeanDefinitionStoreException {
    Assert.hasText(beanName, "Bean name must not be empty");
    Assert.notNull(beanDefinition, "BeanDefinition must not be null");
    if (beanDefinition instanceof AbstractBeanDefinition) {
        try {
            // 注册前的最后一次校验
            ((AbstractBeanDefinition)beanDefinition).validate();
        } catch (BeanDefinitionValidationException var8) {
            throw new BeanDefinitionStoreException(beanDefinition.getResourceDescription(), beanName, "Validation of bean definition failed", var8);
        }
    }
    // 处理beanName已经注册的情况
    BeanDefinition existingDefinition = (BeanDefinition)this.beanDefinitionMap.get(beanName);
    if (existingDefinition != null) {
        // 如果对应BeanName已经注册且在配置中配置了bean不允许被覆盖,则抛出异常
        if (!this.isAllowBeanDefinitionOverriding()) {
            throw new BeanDefinitionOverrideException(beanName, beanDefinition, existingDefinition);
        }

        if (existingDefinition.getRole() < beanDefinition.getRole()) {
            if (this.logger.isInfoEnabled()) {
                this.logger.info("Overriding user-defined bean definition for bean "" + beanName + "" with a framework-generated bean definition: replacing [" + existingDefinition + "] with [" + beanDefinition + "]");
            }
        } else if (!beanDefinition.equals(existingDefinition)) {
            if (this.logger.isDebugEnabled()) {
                this.logger.debug("Overriding bean definition for bean "" + beanName + "" with a different definition: replacing [" + existingDefinition + "] with [" + beanDefinition + "]");
            }
        } else if (this.logger.isTraceEnabled()) {
            this.logger.trace("Overriding bean definition for bean "" + beanName + "" with an equivalent definition: replacing [" + existingDefinition + "] with [" + beanDefinition + "]");
        }

        this.beanDefinitionMap.put(beanName, beanDefinition);
    } else {
        // 检查工厂是否处于bean创建阶段
        if (this.hasBeanCreationStarted()) {
            // 因为beanDefinitionMap是全局变量,会存在并发访问的情况
            synchronized(this.beanDefinitionMap) {
                this.beanDefinitionMap.put(beanName, beanDefinition);
                List<String> updatedDefinitions = new ArrayList(this.beanDefinitionNames.size() + 1);
                updatedDefinitions.addAll(this.beanDefinitionNames);
                updatedDefinitions.add(beanName);
                this.beanDefinitionNames = updatedDefinitions;
                this.removeManualSingletonName(beanName);
            }
        } else {
            // 注册beanDefinition
            this.beanDefinitionMap.put(beanName, beanDefinition);
            // 记录beanName
            this.beanDefinitionNames.add(beanName);
            this.removeManualSingletonName(beanName);
        }

        this.frozenBeanDefinitionNames = null;
    }

    if (existingDefinition == null && !this.containsSingleton(beanName)) {
        if (this.isConfigurationFrozen()) {
            this.clearByTypeCache();
        }
    } else {
        this.resetBeanDefinition(beanName);
    }
}

在对于 bean 的注册处理方式上,主要进行了几个步骤:

  1. 对 AbstractBeanDefinition 校验
  2. 加入 map 缓存
  3. 清楚解析之前留下的对应的 beanName 的缓存

2. 通过别名注册 BeanDefinition

public void registerAlias(String name, String alias) {
    Assert.hasText(name, ""name" must not be empty");
    Assert.hasText(alias, ""alias" must not be empty");
    synchronized(this.aliasMap) {
        // 如果beanName和alias相同的话不记录alias,并删除对应的alias
        if (alias.equals(name)) {
            this.aliasMap.remove(alias);
            if (this.logger.isDebugEnabled()) {
                this.logger.debug("Alias definition "" + alias + "" ignored since it points to same name");
            }
        } else {
            String registeredName = (String)this.aliasMap.get(alias);
            if (registeredName != null) {
                if (registeredName.equals(name)) {
                    return;
                }

                if (!this.allowAliasOverriding()) {
                    throw new IllegalStateException("Cannot define alias "" + alias + "" for name "" + name + "": It is already registered for name "" + registeredName + "".");
                }

                if (this.logger.isDebugEnabled()) {
                    this.logger.debug("Overriding alias "" + alias + "" definition for registered name "" + registeredName + "" with new target name "" + name + """);
                }
            }
			// 检查是否存在循环指向,如A->B,A->C->B
            this.checkForAliasCircle(name, alias);
            this.aliasMap.put(alias, name);
            if (this.logger.isTraceEnabled()) {
                this.logger.trace("Alias definition "" + alias + "" registered for name "" + name + """);
            }
        }
    }
}

注册 alias 的步骤如下:

  1. alias 与 beanName 相同情况处理
  2. alias 循环检查
  3. 注册 alias

hmoban主题是根据ripro二开的主题,极致后台体验,无插件,集成会员系统
自学咖网 » Spring Bean 标签解析
