wen 通过Go语言创建CA与签发证书
本篇文章中，将描述如何使用go创建CA，并使用CA签署证书。在使用openssl创建证书时，遵循的步骤是 创建秘钥 > 创建CA > 生成要颁发证书的秘钥 > 使用CA签发证书。这种步骤，那么我们现在就来尝试下。
创建证书的颁发机构
首先，会从将从创建 CA 开始。CA 会被用来签署其他证书
// 对证书进行签名
ca := &x509.Certificate{
SerialNumber: big.NewInt(2019),
Subject: pkix.Name{
CommonName: "domain name",
Organization: []string{"Company, INC."},
Country: []string{"US"},
Province: []string{""},
Locality: []string{"San Francisco"},
StreetAddress: []string{"Golden Gate Bridge"},
PostalCode: []string{"94016"},
},
NotBefore: time.Now(), // 生效时间
NotAfter: time.Now().AddDate(10, 0, 0), // 过期时间 年月日
IsCA: true, // 表示用于CA
// openssl 中的 extendedKeyUsage = clientAuth, serverAuth 字段
ExtKeyUsage: []x509.ExtKeyUsage{x509.ExtKeyUsageClientAuth, x509.ExtKeyUsageServerAuth},
// openssl 中的 keyUsage 字段
KeyUsage: x509.KeyUsageDigitalSignature | x509.KeyUsageCertSign,
BasicConstraintsValid: true,
}
接下来需要对证书生成公钥和私钥
caPrivKey, err := rsa.GenerateKey(rand.Reader, 4096)
if err != nil {
return err
}
然后生成证书：
caBytes, err := x509.CreateCertificate(rand.Reader, ca, ca, &caPrivKey.PublicKey, caPrivKey)
if err != nil {
return err
}
我们看到的证书内容是PEM编码后的，现在caBytes我们有了生成的证书，我们将其进行 PEM 编码以供以后使用：
caPEM := new(bytes.Buffer)
pem.Encode(caPEM, &pem.Block{
Type: "CERTIFICATE",
Bytes: caBytes,
})
caPrivKeyPEM := new(bytes.Buffer)
pem.Encode(caPrivKeyPEM, &pem.Block{
Type: "RSA PRIVATE KEY",
Bytes: x509.MarshalPKCS1PrivateKey(caPrivKey),
})
创建证书
证书的 x509.Certificate 与CA的 x509.Certificate 属性有稍微不同，需要进行一些修改
cert := &x509.Certificate{
SerialNumber: big.NewInt(1658),
Subject: pkix.Name{
CommonName: "domain name",
Organization: []string{"Company, INC."},
Country: []string{"US"},
Province: []string{""},
Locality: []string{"San Francisco"},
StreetAddress: []string{"Golden Gate Bridge"},
PostalCode: []string{"94016"},
},
IPAddresses: []net.IP{}, // 这里就是openssl配置文件中 subjectAltName 里的 IP:/IP=
DNSNames: []string{}, // 这里就是openssl配置文件中 subjectAltName 里的 DNS:/DNS=
NotBefore: time.Now(),
NotAfter: time.Now().AddDate(10, 0, 0),
SubjectKeyId: []byte{1, 2, 3, 4, 6},
// 这里就是openssl中的extendedKeyUsage
ExtKeyUsage: []x509.ExtKeyUsage{x509.ExtKeyUsageClientAuth, x509.ExtKeyUsageServerAuth},
KeyUsage: x509.KeyUsageDigitalSignature,
}
注：这里会在证书中特别添加了
DNS和IP（这个不是必须的），这个选项的增加代表的我们的证书可以支持多域名
为该证书创建私钥和公钥：
certPrivKey, err := rsa.GenerateKey(rand.Reader, 4096)
if err != nil {
return err
}
使用CA签署证书
有了上述的内容后，可以创建证书并用CA进行签名
certBytes, err := x509.CreateCertificate(rand.Reader, cert, ca, &certPrivKey.PublicKey, caPrivKey)
if err != nil {
return err
}
要保存成证书格式需要做PEM编码
certPEM := new(bytes.Buffer)
pem.Encode(certPEM, &pem.Block{
Type: "CERTIFICATE",
Bytes: certBytes,
})
certPrivKeyPEM := new(bytes.Buffer)
pem.Encode(certPrivKeyPEM, &pem.Block{
Type: "RSA PRIVATE KEY",
Bytes: x509.MarshalPKCS1PrivateKey(certPrivKey),
})
把上面内容融合为一起
创建一个 ca.go 里面是创建ca和颁发证书的逻辑
package main
import (
"bytes"
cr "crypto/rand"
"crypto/rsa"
"crypto/x509"
"crypto/x509/pkix"
"encoding/pem"
"math/big"
"math/rand"
"net"
"os"
"time"
)
type CERT struct {
CERT []byte
CERTKEY *rsa.PrivateKey
CERTPEM *bytes.Buffer
CERTKEYPEM *bytes.Buffer
CSR *x509.Certificate
}
func CreateCA(sub *pkix.Name, expire int) (*CERT, error) {
var (
ca = new(CERT)
err error
)
if expire < 1 {
expire = 1
}
// 为ca生成私钥
ca.CERTKEY, err = rsa.GenerateKey(cr.Reader, 4096)
if err != nil {
return nil, err
}
// 对证书进行签名
ca.CSR = &x509.Certificate{
SerialNumber: big.NewInt(rand.Int63n(2000)),
Subject: *sub,
NotBefore: time.Now(), // 生效时间
NotAfter: time.Now().AddDate(expire, 0, 0), // 过期时间
IsCA: true, // 表示用于CA
// openssl 中的 extendedKeyUsage = clientAuth, serverAuth 字段
ExtKeyUsage: []x509.ExtKeyUsage{x509.ExtKeyUsageClientAuth, x509.ExtKeyUsageServerAuth},
// openssl 中的 keyUsage 字段
KeyUsage: x509.KeyUsageDigitalSignature | x509.KeyUsageCertSign,
BasicConstraintsValid: true,
}
// 创建证书
// caBytes 就是生成的证书
ca.CERT, err = x509.CreateCertificate(cr.Reader, ca.CSR, ca.CSR, &ca.CERTKEY.PublicKey, ca.CERTKEY)
if err != nil {
return nil, err
}
ca.CERTPEM = new(bytes.Buffer)
pem.Encode(ca.CERTPEM, &pem.Block{
Type: "CERTIFICATE",
Bytes: ca.CERT,
})
ca.CERTKEYPEM = new(bytes.Buffer)
pem.Encode(ca.CERTKEYPEM, &pem.Block{
Type: "RSA PRIVATE KEY",
Bytes: x509.MarshalPKCS1PrivateKey(ca.CERTKEY),
})
// 进行PEM编码，编码就是直接cat证书里面内容显示的东西
return ca, nil
}
func Req(ca *x509.Certificate, sub *pkix.Name, expire int, dns []string, ip []net.IP) (*CERT, error) {
var (
cert = &CERT{}
err error
)
cert.CERTKEY, err = rsa.GenerateKey(cr.Reader, 4096)
if err != nil {
return nil, err
}
if expire < 1 {
expire = 1
}
cert.CSR = &x509.Certificate{
SerialNumber: big.NewInt(rand.Int63n(2000)),
Subject: *sub,
IPAddresses: ip,
DNSNames: dns,
NotBefore: time.Now(),
NotAfter: time.Now().AddDate(expire, 0, 0),
SubjectKeyId: []byte{1, 2, 3, 4, 6},
ExtKeyUsage: []x509.ExtKeyUsage{x509.ExtKeyUsageClientAuth, x509.ExtKeyUsageServerAuth},
KeyUsage: x509.KeyUsageDigitalSignature,
}
cert.CERT, err = x509.CreateCertificate(cr.Reader, cert.CSR, ca, &cert.CERTKEY.PublicKey, cert.CERTKEY)
if err != nil {
return nil, err
}
cert.CERTPEM = new(bytes.Buffer)
pem.Encode(cert.CERTPEM, &pem.Block{
Type: "CERTIFICATE",
Bytes: cert.CERT,
})
cert.CERTKEYPEM = new(bytes.Buffer)
pem.Encode(cert.CERTKEYPEM, &pem.Block{
Type: "RSA PRIVATE KEY",
Bytes: x509.MarshalPKCS1PrivateKey(cert.CERTKEY),
})
return cert, nil
}
func Write(cert *CERT, file string) error {
keyFileName := file + ".key"
certFIleName := file + ".crt"
kf, err := os.Create(keyFileName)
if err != nil {
return err
}
defer kf.Close()
if _, err := kf.Write(cert.CERTKEYPEM.Bytes()); err != nil {
return err
}
cf, err := os.Create(certFIleName)
if err != nil {
return err
}
if _, err := cf.Write(cert.CERTPEM.Bytes()); err != nil {
return err
}
return nil
}
如果需要使用的话，可以引用这些函数
package main
import (
"crypto/x509/pkix"
"log"
"net"
)
func main() {
subj := &pkix.Name{
CommonName: "chinamobile.com",
Organization: []string{"Company, INC."},
Country: []string{"US"},
Province: []string{""},
Locality: []string{"San Francisco"},
StreetAddress: []string{"Golden Gate Bridge"},
PostalCode: []string{"94016"},
}
ca, err := CreateCA(subj, 10)
if err != nil {
log.Panic(err)
}
Write(ca, "./ca")
crt, err := Req(ca.CSR, subj, 10, []string{"test.default.svc", "test"}, []net.IP{})
if err != nil {
log.Panic(err)
}
Write(crt, "./tls")
}
遇到的问题
panic: x509: unsupported public key type: rsa.PublicKey
这里是因为 x509.CreateCertificate 的参数 privatekey 需要传入引用变量，而传入的是一个普通变量
注：x509: only RSA and ECDSA public keys supported
一些参数的意思
extendedKeyUsage ：增强型密钥用法(参见”new_oids”字段)：服务器身份验证、客户端身份验证、时间戳。
extendedKeyUsage = critical,serverAuth, clientAuth, timeStamping
keyUsage ： 密钥用法，防否认(nonRepudiation)、数字签名(digitalSignature)、密钥加密(keyEncipherment)。
keyUsage = nonRepudiation, digitalSignature, keyEncipherment
