docker安装nacos 1.x版本

docker安装nacos

拉取版本对应镜像
```
docker pull nacos/nacos-server:1.4.2
```

创建配置文件

vim /usr/local/nacos/init.d/custom.properties

修改配置文件

server.contextPath=/nacos
server.servlet.contextPath=/nacos
server.port=8848

spring.datasource.platform=mysql
db.num=1
db.url.0=jdbc:mysql://xx.xx.xx.x:3306/nacos_devtest_prod?characterEncoding=utf8&connectTimeout=1000&socketTimeout=3000&autoReconnect=true
db.user=user
db.password=pass

nacos.cmdb.dumpTaskInterval=3600
nacos.cmdb.eventTaskInterval=10
nacos.cmdb.labelTaskInterval=300
nacos.cmdb.loadDataAtStart=false
management.metrics.export.elastic.enabled=false
management.metrics.export.influx.enabled=false
server.tomcat.accesslog.enabled=true
server.tomcat.accesslog.pattern=%h %l %u %t "%r" %s %b %D %{User-Agent}i
nacos.security.ignore.urls=/,/**/*.css,/**/*.js,/**/*.html,/**/*.map,/**/*.svg,/**/*.png,/**/*.ico,/console-fe/public/**,/v1/auth/login,/v1/console/health/**,/v1/cs/**,/v1/ns/**,/v1/cmdb/**,/actuator/**,/v1/console/server/**
nacos.naming.distro.taskDispatchThreadCount=1
nacos.naming.distro.taskDispatchPeriod=200
nacos.naming.distro.batchSyncKeyCount=1000
nacos.naming.distro.initDataRatio=0.9
nacos.naming.distro.syncRetryDelay=5000
nacos.naming.data.warmup=true
nacos.naming.expireInstance=true

在nacos官网拿到对应版本的mysql数据库建表语句,这里用的是1.x版本的

/*
 * Copyright 1999-2018 Alibaba Group Holding Ltd.
 *
 * Licensed under the Apache License, Version 2.0 (the "License");
 * you may not use this file except in compliance with the License.
 * You may obtain a copy of the License at
 *
 *      http://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS,
 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
 * See the License for the specific language governing permissions and
 * limitations under the License.
 */

/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = config_info   */
/******************************************/
CREATE TABLE `config_info` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
  `data_id` varchar(255) NOT NULL COMMENT "data_id",
  `group_id` varchar(255) DEFAULT NULL,
  `content` longtext NOT NULL COMMENT "content",
  `md5` varchar(32) DEFAULT NULL COMMENT "md5",
  `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
  `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
  `src_user` text COMMENT "source user",
  `src_ip` varchar(20) DEFAULT NULL COMMENT "source ip",
  `app_name` varchar(128) DEFAULT NULL,
  `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
  `c_desc` varchar(256) DEFAULT NULL,
  `c_use` varchar(64) DEFAULT NULL,
  `effect` varchar(64) DEFAULT NULL,
  `type` varchar(64) DEFAULT NULL,
  `c_schema` text,
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_configinfo_datagrouptenant` (`data_id`,`group_id`,`tenant_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_info";

/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = config_info_aggr   */
/******************************************/
CREATE TABLE `config_info_aggr` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
  `data_id` varchar(255) NOT NULL COMMENT "data_id",
  `group_id` varchar(255) NOT NULL COMMENT "group_id",
  `datum_id` varchar(255) NOT NULL COMMENT "datum_id",
  `content` longtext NOT NULL COMMENT "内容",
  `gmt_modified` datetime NOT NULL COMMENT "修改时间",
  `app_name` varchar(128) DEFAULT NULL,
  `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_configinfoaggr_datagrouptenantdatum` (`data_id`,`group_id`,`tenant_id`,`datum_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="增加租户字段";


/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = config_info_beta   */
/******************************************/
CREATE TABLE `config_info_beta` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
  `data_id` varchar(255) NOT NULL COMMENT "data_id",
  `group_id` varchar(128) NOT NULL COMMENT "group_id",
  `app_name` varchar(128) DEFAULT NULL COMMENT "app_name",
  `content` longtext NOT NULL COMMENT "content",
  `beta_ips` varchar(1024) DEFAULT NULL COMMENT "betaIps",
  `md5` varchar(32) DEFAULT NULL COMMENT "md5",
  `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
  `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
  `src_user` text COMMENT "source user",
  `src_ip` varchar(20) DEFAULT NULL COMMENT "source ip",
  `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_configinfobeta_datagrouptenant` (`data_id`,`group_id`,`tenant_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_info_beta";

/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = config_info_tag   */
/******************************************/
CREATE TABLE `config_info_tag` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
  `data_id` varchar(255) NOT NULL COMMENT "data_id",
  `group_id` varchar(128) NOT NULL COMMENT "group_id",
  `tenant_id` varchar(128) DEFAULT "" COMMENT "tenant_id",
  `tag_id` varchar(128) NOT NULL COMMENT "tag_id",
  `app_name` varchar(128) DEFAULT NULL COMMENT "app_name",
  `content` longtext NOT NULL COMMENT "content",
  `md5` varchar(32) DEFAULT NULL COMMENT "md5",
  `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
  `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
  `src_user` text COMMENT "source user",
  `src_ip` varchar(20) DEFAULT NULL COMMENT "source ip",
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_configinfotag_datagrouptenanttag` (`data_id`,`group_id`,`tenant_id`,`tag_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_info_tag";

/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = config_tags_relation   */
/******************************************/
CREATE TABLE `config_tags_relation` (
  `id` bigint(20) NOT NULL COMMENT "id",
  `tag_name` varchar(128) NOT NULL COMMENT "tag_name",
  `tag_type` varchar(64) DEFAULT NULL COMMENT "tag_type",
  `data_id` varchar(255) NOT NULL COMMENT "data_id",
  `group_id` varchar(128) NOT NULL COMMENT "group_id",
  `tenant_id` varchar(128) DEFAULT "" COMMENT "tenant_id",
  `nid` bigint(20) NOT NULL AUTO_INCREMENT,
  PRIMARY KEY (`nid`),
  UNIQUE KEY `uk_configtagrelation_configidtag` (`id`,`tag_name`,`tag_type`),
  KEY `idx_tenant_id` (`tenant_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_tag_relation";

/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = group_capacity   */
/******************************************/
CREATE TABLE `group_capacity` (
  `id` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT "主键ID",
  `group_id` varchar(128) NOT NULL DEFAULT "" COMMENT "Group ID，空字符表示整个集群",
  `quota` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "配额，0表示使用默认值",
  `usage` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "使用量",
  `max_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个配置大小上限，单位为字节，0表示使用默认值",
  `max_aggr_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "聚合子配置最大个数，，0表示使用默认值",
  `max_aggr_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个聚合数据的子配置大小上限，单位为字节，0表示使用默认值",
  `max_history_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "最大变更历史数量",
  `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
  `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_group_id` (`group_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="集群、各Group容量信息表";

/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = his_config_info   */
/******************************************/
CREATE TABLE `his_config_info` (
  `id` bigint(64) unsigned NOT NULL,
  `nid` bigint(20) unsigned NOT NULL AUTO_INCREMENT,
  `data_id` varchar(255) NOT NULL,
  `group_id` varchar(128) NOT NULL,
  `app_name` varchar(128) DEFAULT NULL COMMENT "app_name",
  `content` longtext NOT NULL,
  `md5` varchar(32) DEFAULT NULL,
  `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00",
  `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00",
  `src_user` text,
  `src_ip` varchar(20) DEFAULT NULL,
  `op_type` char(10) DEFAULT NULL,
  `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
  PRIMARY KEY (`nid`),
  KEY `idx_gmt_create` (`gmt_create`),
  KEY `idx_gmt_modified` (`gmt_modified`),
  KEY `idx_did` (`data_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="多租户改造";


/******************************************/
/*   数据库全名 = nacos_config   */
/*   表名称 = tenant_capacity   */
/******************************************/
CREATE TABLE `tenant_capacity` (
  `id` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT "主键ID",
  `tenant_id` varchar(128) NOT NULL DEFAULT "" COMMENT "Tenant ID",
  `quota` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "配额，0表示使用默认值",
  `usage` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "使用量",
  `max_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个配置大小上限，单位为字节，0表示使用默认值",
  `max_aggr_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "聚合子配置最大个数",
  `max_aggr_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个聚合数据的子配置大小上限，单位为字节，0表示使用默认值",
  `max_history_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "最大变更历史数量",
  `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
  `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_tenant_id` (`tenant_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="租户容量信息表";


CREATE TABLE `tenant_info` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
  `kp` varchar(128) NOT NULL COMMENT "kp",
  `tenant_id` varchar(128) default "" COMMENT "tenant_id",
  `tenant_name` varchar(128) default "" COMMENT "tenant_name",
  `tenant_desc` varchar(256) DEFAULT NULL COMMENT "tenant_desc",
  `create_source` varchar(32) DEFAULT NULL COMMENT "create_source",
  `gmt_create` bigint(20) NOT NULL COMMENT "创建时间",
  `gmt_modified` bigint(20) NOT NULL COMMENT "修改时间",
  PRIMARY KEY (`id`),
  UNIQUE KEY `uk_tenant_info_kptenantid` (`kp`,`tenant_id`),
  KEY `idx_tenant_id` (`tenant_id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="tenant_info";

CREATE TABLE users (
	username varchar(50) NOT NULL PRIMARY KEY,
	password varchar(500) NOT NULL,
	enabled boolean NOT NULL
);

CREATE TABLE roles (
	username varchar(50) NOT NULL,
	role varchar(50) NOT NULL,
	constraint uk_username_role UNIQUE (username,role)
);

CREATE TABLE permissions (
    role varchar(50) NOT NULL,
    resource varchar(512) NOT NULL,
    action varchar(8) NOT NULL,
    constraint uk_role_permission UNIQUE (role,resource,action)
);

INSERT INTO users (username, password, enabled) VALUES ("nacos", "$2a$10$EuWPZHzz32dJN7jexM34MOeYirDdFAZm2kuWj7VEOJhhZkDrxfvUu", TRUE);

INSERT INTO roles (username, role) VALUES ("nacos", "ROLE_ADMIN");

启动容器

docker  run
--name nacos -d
-p 8848:8848
--privileged=true
--restart=always
-e JVM_XMS=256m
-e JVM_XMX=256m
-e MODE=standalone
-e PREFER_HOST_MODE=hostname
-v /usr/local/nacos/logs:/home/nacos/logs
-v /usr/local/nacos/init.d/custom.properties:/home/nacos/init.d/custom.properties
nacos/nacos-server:1.4.2
