docker安装nacos 1.x版本

docker安装nacos 1.x版本

docker安装nacos

  • 拉取版本对应镜像

    docker pull nacos/nacos-server:1.4.2

  • 创建配置文件

    vim /usr/local/nacos/init.d/custom.properties

  • 修改配置文件

    server.contextPath=/nacos
    server.servlet.contextPath=/nacos
    server.port=8848

    spring.datasource.platform=mysql
    db.num=1
    db.url.0=jdbc:mysql://xx.xx.xx.x:3306/nacos_devtest_prod?characterEncoding=utf8&connectTimeout=1000&socketTimeout=3000&autoReconnect=true
    db.user=user
    db.password=pass

    nacos.cmdb.dumpTaskInterval=3600
    nacos.cmdb.eventTaskInterval=10
    nacos.cmdb.labelTaskInterval=300
    nacos.cmdb.loadDataAtStart=false
    management.metrics.export.elastic.enabled=false
    management.metrics.export.influx.enabled=false
    server.tomcat.accesslog.enabled=true
    server.tomcat.accesslog.pattern=%h %l %u %t "%r" %s %b %D %{User-Agent}i
    nacos.security.ignore.urls=/,/**/*.css,/**/*.js,/**/*.html,/**/*.map,/**/*.svg,/**/*.png,/**/*.ico,/console-fe/public/**,/v1/auth/login,/v1/console/health/**,/v1/cs/**,/v1/ns/**,/v1/cmdb/**,/actuator/**,/v1/console/server/**
    nacos.naming.distro.taskDispatchThreadCount=1
    nacos.naming.distro.taskDispatchPeriod=200
    nacos.naming.distro.batchSyncKeyCount=1000
    nacos.naming.distro.initDataRatio=0.9
    nacos.naming.distro.syncRetryDelay=5000
    nacos.naming.data.warmup=true
    nacos.naming.expireInstance=true

  • 在nacos官网拿到对应版本的mysql数据库建表语句,这里用的是1.x版本的

    /*
     * Copyright 1999-2018 Alibaba Group Holding Ltd.
     *
     * Licensed under the Apache License, Version 2.0 (the "License");
     * you may not use this file except in compliance with the License.
     * You may obtain a copy of the License at
     *
     *      http://www.apache.org/licenses/LICENSE-2.0
     *
     * Unless required by applicable law or agreed to in writing, software
     * distributed under the License is distributed on an "AS IS" BASIS,
     * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
     * See the License for the specific language governing permissions and
     * limitations under the License.
     */

    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = config_info   */
    /******************************************/
    CREATE TABLE `config_info` (
      `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
      `data_id` varchar(255) NOT NULL COMMENT "data_id",
      `group_id` varchar(255) DEFAULT NULL,
      `content` longtext NOT NULL COMMENT "content",
      `md5` varchar(32) DEFAULT NULL COMMENT "md5",
      `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
      `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
      `src_user` text COMMENT "source user",
      `src_ip` varchar(20) DEFAULT NULL COMMENT "source ip",
      `app_name` varchar(128) DEFAULT NULL,
      `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
      `c_desc` varchar(256) DEFAULT NULL,
      `c_use` varchar(64) DEFAULT NULL,
      `effect` varchar(64) DEFAULT NULL,
      `type` varchar(64) DEFAULT NULL,
      `c_schema` text,
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_configinfo_datagrouptenant` (`data_id`,`group_id`,`tenant_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_info";

    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = config_info_aggr   */
    /******************************************/
    CREATE TABLE `config_info_aggr` (
      `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
      `data_id` varchar(255) NOT NULL COMMENT "data_id",
      `group_id` varchar(255) NOT NULL COMMENT "group_id",
      `datum_id` varchar(255) NOT NULL COMMENT "datum_id",
      `content` longtext NOT NULL COMMENT "内容",
      `gmt_modified` datetime NOT NULL COMMENT "修改时间",
      `app_name` varchar(128) DEFAULT NULL,
      `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_configinfoaggr_datagrouptenantdatum` (`data_id`,`group_id`,`tenant_id`,`datum_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="增加租户字段";


    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = config_info_beta   */
    /******************************************/
    CREATE TABLE `config_info_beta` (
      `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
      `data_id` varchar(255) NOT NULL COMMENT "data_id",
      `group_id` varchar(128) NOT NULL COMMENT "group_id",
      `app_name` varchar(128) DEFAULT NULL COMMENT "app_name",
      `content` longtext NOT NULL COMMENT "content",
      `beta_ips` varchar(1024) DEFAULT NULL COMMENT "betaIps",
      `md5` varchar(32) DEFAULT NULL COMMENT "md5",
      `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
      `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
      `src_user` text COMMENT "source user",
      `src_ip` varchar(20) DEFAULT NULL COMMENT "source ip",
      `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_configinfobeta_datagrouptenant` (`data_id`,`group_id`,`tenant_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_info_beta";

    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = config_info_tag   */
    /******************************************/
    CREATE TABLE `config_info_tag` (
      `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
      `data_id` varchar(255) NOT NULL COMMENT "data_id",
      `group_id` varchar(128) NOT NULL COMMENT "group_id",
      `tenant_id` varchar(128) DEFAULT "" COMMENT "tenant_id",
      `tag_id` varchar(128) NOT NULL COMMENT "tag_id",
      `app_name` varchar(128) DEFAULT NULL COMMENT "app_name",
      `content` longtext NOT NULL COMMENT "content",
      `md5` varchar(32) DEFAULT NULL COMMENT "md5",
      `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
      `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
      `src_user` text COMMENT "source user",
      `src_ip` varchar(20) DEFAULT NULL COMMENT "source ip",
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_configinfotag_datagrouptenanttag` (`data_id`,`group_id`,`tenant_id`,`tag_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_info_tag";

    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = config_tags_relation   */
    /******************************************/
    CREATE TABLE `config_tags_relation` (
      `id` bigint(20) NOT NULL COMMENT "id",
      `tag_name` varchar(128) NOT NULL COMMENT "tag_name",
      `tag_type` varchar(64) DEFAULT NULL COMMENT "tag_type",
      `data_id` varchar(255) NOT NULL COMMENT "data_id",
      `group_id` varchar(128) NOT NULL COMMENT "group_id",
      `tenant_id` varchar(128) DEFAULT "" COMMENT "tenant_id",
      `nid` bigint(20) NOT NULL AUTO_INCREMENT,
      PRIMARY KEY (`nid`),
      UNIQUE KEY `uk_configtagrelation_configidtag` (`id`,`tag_name`,`tag_type`),
      KEY `idx_tenant_id` (`tenant_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="config_tag_relation";

    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = group_capacity   */
    /******************************************/
    CREATE TABLE `group_capacity` (
      `id` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT "主键ID",
      `group_id` varchar(128) NOT NULL DEFAULT "" COMMENT "Group ID,空字符表示整个集群",
      `quota` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "配额,0表示使用默认值",
      `usage` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "使用量",
      `max_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个配置大小上限,单位为字节,0表示使用默认值",
      `max_aggr_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "聚合子配置最大个数,,0表示使用默认值",
      `max_aggr_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个聚合数据的子配置大小上限,单位为字节,0表示使用默认值",
      `max_history_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "最大变更历史数量",
      `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
      `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_group_id` (`group_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="集群、各Group容量信息表";

    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = his_config_info   */
    /******************************************/
    CREATE TABLE `his_config_info` (
      `id` bigint(64) unsigned NOT NULL,
      `nid` bigint(20) unsigned NOT NULL AUTO_INCREMENT,
      `data_id` varchar(255) NOT NULL,
      `group_id` varchar(128) NOT NULL,
      `app_name` varchar(128) DEFAULT NULL COMMENT "app_name",
      `content` longtext NOT NULL,
      `md5` varchar(32) DEFAULT NULL,
      `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00",
      `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00",
      `src_user` text,
      `src_ip` varchar(20) DEFAULT NULL,
      `op_type` char(10) DEFAULT NULL,
      `tenant_id` varchar(128) DEFAULT "" COMMENT "租户字段",
      PRIMARY KEY (`nid`),
      KEY `idx_gmt_create` (`gmt_create`),
      KEY `idx_gmt_modified` (`gmt_modified`),
      KEY `idx_did` (`data_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="多租户改造";


    /******************************************/
    /*   数据库全名 = nacos_config   */
    /*   表名称 = tenant_capacity   */
    /******************************************/
    CREATE TABLE `tenant_capacity` (
      `id` bigint(20) unsigned NOT NULL AUTO_INCREMENT COMMENT "主键ID",
      `tenant_id` varchar(128) NOT NULL DEFAULT "" COMMENT "Tenant ID",
      `quota` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "配额,0表示使用默认值",
      `usage` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "使用量",
      `max_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个配置大小上限,单位为字节,0表示使用默认值",
      `max_aggr_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "聚合子配置最大个数",
      `max_aggr_size` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "单个聚合数据的子配置大小上限,单位为字节,0表示使用默认值",
      `max_history_count` int(10) unsigned NOT NULL DEFAULT "0" COMMENT "最大变更历史数量",
      `gmt_create` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "创建时间",
      `gmt_modified` datetime NOT NULL DEFAULT "2010-05-05 00:00:00" COMMENT "修改时间",
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_tenant_id` (`tenant_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="租户容量信息表";


    CREATE TABLE `tenant_info` (
      `id` bigint(20) NOT NULL AUTO_INCREMENT COMMENT "id",
      `kp` varchar(128) NOT NULL COMMENT "kp",
      `tenant_id` varchar(128) default "" COMMENT "tenant_id",
      `tenant_name` varchar(128) default "" COMMENT "tenant_name",
      `tenant_desc` varchar(256) DEFAULT NULL COMMENT "tenant_desc",
      `create_source` varchar(32) DEFAULT NULL COMMENT "create_source",
      `gmt_create` bigint(20) NOT NULL COMMENT "创建时间",
      `gmt_modified` bigint(20) NOT NULL COMMENT "修改时间",
      PRIMARY KEY (`id`),
      UNIQUE KEY `uk_tenant_info_kptenantid` (`kp`,`tenant_id`),
      KEY `idx_tenant_id` (`tenant_id`)
    ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_bin COMMENT="tenant_info";

    CREATE TABLE users (
    	username varchar(50) NOT NULL PRIMARY KEY,
    	password varchar(500) NOT NULL,
    	enabled boolean NOT NULL
    );

    CREATE TABLE roles (
    	username varchar(50) NOT NULL,
    	role varchar(50) NOT NULL,
    	constraint uk_username_role UNIQUE (username,role)
    );

    CREATE TABLE permissions (
        role varchar(50) NOT NULL,
        resource varchar(512) NOT NULL,
        action varchar(8) NOT NULL,
        constraint uk_role_permission UNIQUE (role,resource,action)
    );

    INSERT INTO users (username, password, enabled) VALUES ("nacos", "$2a$10$EuWPZHzz32dJN7jexM34MOeYirDdFAZm2kuWj7VEOJhhZkDrxfvUu", TRUE);

    INSERT INTO roles (username, role) VALUES ("nacos", "ROLE_ADMIN");

  • 启动容器

    docker  run
    --name nacos -d
    -p 8848:8848
    --privileged=true
    --restart=always
    -e JVM_XMS=256m
    -e JVM_XMX=256m
    -e MODE=standalone
    -e PREFER_HOST_MODE=hostname
    -v /usr/local/nacos/logs:/home/nacos/logs
    -v /usr/local/nacos/init.d/custom.properties:/home/nacos/init.d/custom.properties
    nacos/nacos-server:1.4.2
